The Ford F-150 Platinum is one of Australia’s most sought-after American pickup trucks, combining exceptional towing capability, luxury appointments and advanced suspension technology. A key component of the Platinum’s ride quality is Ford’s Continuously Controlled Damping (CCD) suspension system, which automatically adjusts shock absorber firmness in real time to suit changing road conditions and selected drive modes.
At America’s Garage, we offer a wide range of Ford F-150 suspension upgrades, from 2-6" Lift Kits, premium FOX & Outback Kitters Suspension systems, heavy-duty towing solutions and engineered GVM Upgrade packages designed to improve load carrying capacity, vehicle control and off-road performance. Whether you’re building a touring rig, towing a large caravan or fitting larger wheels and tyres, understanding how the factory CCD system interacts with aftermarket suspension is critical before selecting your lift kit.
If you’re considering upgrading the suspension on your Ford F-150 Platinum, there is one important detail regarding the CCD system that every owner should understand before purchasing aftermarket shocks or a lift kit.
What is CCD?
CCD (Continuously Controlled Damping) is Ford’s electronically controlled shock absorber system. Sensors throughout the vehicle constantly monitor steering input, braking, acceleration, suspension movement and road conditions. The system then adjusts damping rates in real time to improve comfort, handling and vehicle control.
The CCD system works alongside the F-150’s selectable drive modes, including:
- Normal
- Sport
- Tow/Haul
- Slippery (Snow)
- Mud/Ruts
- Sand
- Baja (where equipped)
When functioning correctly, the suspension characteristics automatically change depending on the selected mode.
What Happens When You Install Aftermarket Shocks?
Most aftermarket suspension systems replace the factory electronic shock absorbers with conventional high-performance shocks from brands such as FOX, Outback Kitters or similar manufacturers.
While these shocks often provide improved off-road performance, increased durability and better control with larger tyres, they do not communicate with Ford’s factory CCD control module.
As a result, the vehicle will detect that the factory electronic dampers have been removed and may display warning messages or disable certain drive mode functions.
The CCD Sensors CAN NOT be removed from the Factory Ford Shocks and transferred to aftermarket brands. There are some brands however that have Live Valve / Active Control Dampening systems that may work with Fords OEM system.
Option 1: Retain Full Drive Mode Functionality
For owners who wish to retain all factory drive mode functionality, an additional electronic interface module is required.
This module connects to the vehicle’s factory suspension control system and simulates the presence of the original CCD shocks, allowing the vehicle to continue operating all available drive modes as intended.
Additional module cost: approximately $800 + Installation
Benefits include:
- Retains Normal, Sport, Tow, Snow, Mud, Sand and Baja modes
- Prevents suspension fault warnings
- Maintains factory drive mode integration
- Delivers a more OEM-style user experience
For many Platinum owners, this is the preferred solution because it preserves the premium functionality that makes the Platinum unique.
The truck generally still drives extremely well because the aftermarket shocks are usually tuned to perform better than the factory CCD shocks for off-road use and larger tyres.
The $800 CCD delete/retention modules are mostly about:
- Keeping the dash free of warnings
- Retaining factory drive mode selection
- Maintaining OEM functionality
- Preserving resale appeal
For an Outback Kitters or BDS-equipped F-150 on 35s, many owners would struggle to notice the loss of adaptive damping during everyday driving compared with the improvement gained from a quality aftermarket suspension package. The transmission and throttle calibrations are often what drivers notice most when changing drive modes.
NOTE: The Drive Modes will only affect the drivetrain systems like the gearbox, engine braking, throttle mapping, transmission shifting. The suspension dampening will not change.
Option 2: Disable CCD Through Programming
For customers who do not require the factory adaptive damping functionality, our dealers can provide instructions to disable the CCD system through vehicle programming.
This removes the need for the additional interface module and allows the aftermarket suspension to operate independently.
However, owners should be aware that the vehicle will typically display a message indicating:
“Driving Modes Disabled”
The truck will continue to drive normally with the upgraded suspension, but the factory drive mode integration linked to the CCD system will no longer be available.
This option is commonly chosen by customers who:
- Primarily use their vehicle off-road
- Prefer simplicity over electronic integration
- Want to minimise upgrade costs
- Are focused on suspension performance rather than factory features
If You Disable CCD, What Do You Actually Lose?
This is where it gets interesting.
If you simply disable the CCD suspension system, you are primarily removing the adaptive shock functionality, eliminating the suspension fault codes and removing your ability to access the different Drive Modes.
The reason some vehicles show “Drive Modes Disabled” is that Ford ties the drive mode controller and CCD module together. If the vehicle sees a critical fault in the CCD system, it may disable the entire drive mode menu rather than only disabling suspension adjustments.
If you opt in for the additional Module + Programming, the following can still remain functional:
✅ Throttle mapping changes
✅ Transmission shift strategy changes
✅ Steering calibration changes
✅ Traction control calibration changes
✅ Transfer case logic changes
✅ Trailer sway control functions
What usually disappears is:
❌ Adaptive damping changes
❌ Suspension-specific drive mode tuning
❌ Drive mode integration linked to the CCD module
❌ Factory suspension diagnostics
Which Option is Right for You?
The answer depends on how you use your F-150.
If you purchased a Platinum specifically for its premium technology and want every feature operating exactly as Ford intended, the CCD retention module is usually the best choice.
If your priority is achieving the best possible suspension performance while keeping costs down, disabling CCD may be a perfectly acceptable solution.
Talk to Your Installer Before Ordering
Not all suspension packages require the same components, and CCD-equipped vehicles should always be identified before quoting or ordering parts.
If you’re unsure whether your F-150 is fitted with CCD, the America's Garage dealer network can help identify your vehicle specification and recommend the most suitable upgrade path.
Whether you choose to retain the factory electronic functionality or disable CCD altogether, understanding the options beforehand helps ensure there are no surprises once your new suspension is installed.
Need advice on upgrading your Ford F-150 Platinum suspension? Contact your local dealer and we’ll help you choose the right solution for your vehicle and driving style.
